Sites & Routes

Manage strategic locations (pools, fuel stations, collection points, disposal sites) and routes that connect them. Routes form the daily journey sequence from pool departure through disposal and back.

Sites Tab

Adding a site

1. Select the Sites tab and click the Add Site button.

2. Fill in the site information:

   • Site Type — choose one of:
     • Pool — vehicle storage and departure location
     • SPBU — fuel station
     • TPS — temporary waste collection point
     • TPA — final waste disposal facility
   • Name — site name (example: "Main Pool", "Jalan Merdeka SPBU")
   • Address (optional) — full address of the site

3. Add coordinates (optional):

   • Latitude & Longitude — enter manually or use the interactive map
   • Interactive Map — click on the map to place a pin, or use address search

4. Click Save.

Use the map for accuracy

Click the pin on the map to pinpoint the location accurately. Coordinates will be displayed when vehicles do GPS tracking.

Editing and deleting sites

• Edit — click the edit icon to modify site data.
• Delete — click the delete icon to remove a site (only if not used in any routes).

Searching for sites

Use the search box to find sites by name.

Routes Tab

Routes connect two sites in a specific order. Each route has a category that determines its purpose.

Route types

Route Type	Origin	Destination	Purpose
Depart Pool	Pool	—	Departure from pool (destination auto-set to same pool)
Refuel	Any location	SPBU	Fuel refilling stop
Pickup	Any location	TPS	Waste pickup from collection point
Disposal	Any location	TPA	Waste disposal at facility
Return Pool	Any location	Pool	Return to pool for parking

Adding a route

1. Select the Routes tab and click the Add Route button.

2. Fill in the route information:

   • Route Type — choose a category (Depart Pool, Refuel, Pickup, Disposal, Return Pool)
   • Origin Site — starting location (site type auto-determined by category)
   • Destination Site — ending location (hidden if "Depart Pool")

   The system restricts location choices based on the route type you select. For example, "Refuel" only allows SPBU as the destination.

3. Distance — automatically calculated from the route corridor (once set).

4. Click Save.

Setting up route corridors

A corridor is a reference path on the map used for:

• Calculating distance between sites
• Validating vehicle deviation during GPS tracking

After creating a route:

1. In the routes list, click the Corridor menu in the route's row.
2. A corridor editor panel opens with an interactive map.
3. Draw/edit the corridor line by:
   • Click on map — add corridor points
   • Drag points — move a point
   • Delete points — click a point then delete
4. Click Save Corridor to save.

The route distance will automatically update based on the corridor length.

Searching and filtering routes

• Search box — search by origin or destination site name.
• Route type filter — show only routes of a specific type (Depart Pool, Refuel, etc.).

Editing and deleting routes

• Edit — click the edit icon to modify route data.
• Delete — click the delete icon to remove a route.

Columns in Sites list

Column	Description
Name	Site name
Type	Site type (Pool/SPBU/TPS/TPA)
Address	Full address (if available)
Coordinates	Latitude & longitude; click pin to view on map

Columns in Routes list

Column	Description
Origin Site	Starting location
Destination Site	Ending location
Type	Route category (Depart Pool, Refuel, etc.)
Distance	Distance between sites in km

Required permissions

• View list — site:read permission
• Add/edit sites — site:create or site:update permission
• Delete sites — site:delete permission
• Add/edit routes — route:create or route:update permission
• Delete routes — route:delete permission
• Manage corridors — route-geometry:manage permission

See Roles & Access Control for more information about user permissions.

Important notes

• Origin and destination sites must be different, except for "Depart Pool" and "Return Pool" which reference the same pool.
• Coordinates, if provided, must have both latitude and longitude (cannot be partial).
• Routes cannot be deleted if still used by any schedule templates or daily schedules.
